DAYTON Quiet-Design Industrial Fan: 30" Blade

In Packaging?: Yes
Damaged?: Unknown
Brand: DAYTON
Model: 20955
Standard-duty industrial pedestal fans cool heavy manufacturing areas and other dusty or dirty environments. Compared to light-duty industrial fans, these standard-duty fans are made of heavier-gauge materials, have a higher-horsepower motor that is totally enclosed to keep out debris, and feature more-robust motor bearings for a longer life. Brand: DAYTON Blade Diameter: 30 in Wheeled Base: Stationary Oscillation: Oscillating Watts: 300 Number of Speeds: 3 Voltage: 115V AC Phase: 1 Air Flow: 4,063/5,859/7,996 cfm Motor HP: 1/3 hp RPM: 1045/789/561 Amps: 2.9 Fan Mounting Location: Pedestal Air Velocity @ 10 Ft.: 900/721/540 fpm Air Velocity @ 20 Ft.: 600/480/360 fpm Air Velocity @ 40 Ft.: 350/279/209 fpm Air Velocity @ 60 Ft.: 200/160/120 fpm Air Velocity @ 80 Ft.: 150 fpm Assembly Required: Yes Sound Level: 75/69/63 dBA Max. Ambient Temp.: 105 F Hz: 60 Hz Motor Enclosure: Totally Enclosed Air Over Motor Insulation: Class B Motor Type: Permanent Split Capacitor Thermal Protection: Auto Bearing Type: Ball Fan Cord Length: 15 ft NEMA Plug Configuration: 5-15P Width: 33-5/16 in Depth: 15-3/4 in Number of Blades: 3 Blade Material: Cast Aluminum Shaft Dia.: 5/8 in Fan Housing Material: Steel Guard Material: Steel Wire Guard Finish: Nickel Chrome Number of Conductors: 3 Height Adjustment: 60 to 96 in Drive Type: Direct Drive Standards: UL Includes: Mounting Device and Mounting Bolts Environmental Applications: Industrial Product Type: Standard-Duty Quiet-Design Industrial Fan.
